This machinery is one of the most successful and well proved maize choppers. After harvesting, the stems are carried towards the chopping blades by the feeder chains and then loaded. This short procedure leads to the maximum output (more than 50ton/h). The material of chopping blades is designed to be more stable against the different defects such as trituration, etc.t
| • Technical features | |
|---|---|
| • Power (hp) | minimum 90 |
| • P.T.O Speed (rpm) (optional) | 540 & 1000 |
| • Capacity (ton/h) | 75 |
| • Height (m) | 3.5 |
| • Length (m) | 4.30 |
| • Width (m) | 2.61 |
| • Weight (kg) | 1720 |
| • Chop lengths in mm | |||
|---|---|---|---|
| • No. of the blades | 2 | 4 | 8 |
| • Speed 1 | 16 | 8 | 4 |
| • Speed 2 | 26 | 13 | 6.5 |
| • Speed 3 | 54 | 27 | 13.4 |
